1500kg capacity , 5500mm lifting height Straddle Type Electric Stacker (1.5 ton, 5.5m)

FOB Reference Price:Get Latest Price
1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
MeiShi
Model Number:
CDD15AK
Type:
Powered Pallet Truck
Power Souce:
AC Motor
Rated Loading Capacity:
1500kg
Max. Lifting Height:
5500mm
Min. Lifting Height:
65mm
Fork Length:
1000mm
Fork Width:
210~950mm
Certification:
CE/ISO9001
After-sales Service Provided:
Overseas third-party support available
SupplyAbility
SupplyAbility:
500 Piece/Pieces per Month
Packaging & Delivery
Port
Shanghai
Lead Time :
10~20 days



Product Description





Detailed Product Description of CDDAK AC Motor Lift

Main Character



  • It has free lifting function,and can be used inside the container
  • 3-layer mast with "H-shaped" structure.safe,beautiful and solid
  • Imported control system,pump station and so on,makes good quality
  • Large capacity battery makes the stacker work longer
  • Optional imported handle,guard,pedal and AC motor



Product Model designation



CDD12AK/CDD15AK

Drive Unit



Electric

Operation type



Pedestrian/Standing

Load capacity

kg

1200/1500

Load center

mm

500

Overall length

mm

1891

Overall width

mm

1197-1520

Overall height

mm

2175

2375

2508

Lift height

mm

4500

5000

5500

Max working height

mm

5363

5873

6373

Free lift height

mm

1335

1535

1669

Lowered fork height

mm

65

Fork dimensions

mm

1000×100×35

Maximum fork width

mm

210-950

Min. aisle width for stacking

mm

2565

Wheelbase

mm

1365

Turning radius

mm

1600

Travel speed

loaded

Km/h

5.2

unloaded

Km/h

6.8

Lift speed

loaded

mm/s

120

unloaded

mm/s

170

Lowering speed

loaded

mm/s

150

unloaded

mm/s

128

Brake type



Electric-magnetic

Drive motor power

KW

1.5

lift motor power

KW

3.0

Battery capacity/voltage

Ah/V

240/24

Weight without battery

kg

1195

1245

1295

Battery weight

kg

235



































































-CDD-CDDA

-CDDH
