Detailed Product Description of CBD20S Electric Platform Truck
Main Character
- Top quality controller system from CURTIS, high reliability, ensures best performance in different states.
- WINNER hydraulic power pack, low noise, few vibration and excellent leak tightness, ensures smooth lifting.
- High-strength frame design, suitable for tough workplaces, ensures longer service life.
- Configure with 210Ah large capacity battery, intelligent charger, REMA plug from Germany.
- Optional humanized design of handrail and folded pedal, easy operating.
Identification | Model |
| CBD20 | ||||||||||
Config-code | Standard type |
| S20 | S25 | S30 | ||||||||
With pedal and handrail |
| ST20 | ST25 | ST30 | |||||||||
Drive Unit |
| Electric | |||||||||||
Operation type |
| Pedestrian /Standing | |||||||||||
Load capacity |
| kg | 2000 | 2500 | 3000 | ||||||||
Dimension | Overall length | L | mm | 1781 | |||||||||
Overall width | b | mm | 690 | ||||||||||
Overall height | H2 | mm | 1305 | ||||||||||
Min. fork height | h1 | mm | 75(85) | ||||||||||
Max. fork height | h2 | mm | 195(205) | ||||||||||
Fork dimensions | L1×b2×m | mm | 1150x160x56 | ||||||||||
Maximum fork width | b1 | mm | 530 | 680 | 530 | 680 | 530 | 680 | |||||
Turning radius | Wa | mm | 1608 | ||||||||||
Wheelbase | Y | mm | 1406 | ||||||||||
Performance | Travel speed | loaded | Km/h | 4.6 | 4.3 | 4.1 | |||||||
unloaded | Km/h | 5.4 | |||||||||||
Lift speed | loaded | mm/s | 22 | 31 | 29 | ||||||||
unloaded | mm/s | 32 | 38 | 38 | |||||||||
Lowering speed | loaded | mm/s | 55 | ||||||||||
unloaded | mm/s | 50 | |||||||||||
Gradeability | % | 8 | |||||||||||
Brake type |
| Electric-magnetic | |||||||||||
Electric Motor | Gradeability | KW | 1.2 | ||||||||||
Brake type | KW | 0.8 | 2.0 | 2.0 | |||||||||
Drive motor power | Ah/V | 210/24 | |||||||||||
Weight | Lift motor power | kg | 324 | 329 | 338 | 343 | 352 | 357 | |||||
Battery | kg | 185 | |||||||||||
Our factory has been built up for about 40 years. We are a Manufactory which mainly produce Electric forklifts, includes Electric Pallet Truck, Electric Stacker, Electric Reach Truck and so on. We do OEM for many trading companies. Our products mainly exported to European Market.
