1000kg 3200mm Electric Forklift

FOB Reference Price:Get Latest Price
US $6,300-7,300 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
MeiShi
Model Number:
CPD10S
Type:
forklift
Power Souce:
DC Motor
Rated Loading Capacity:
1000kg
Max. Lifting Height:
2500/3200mm
Min. Lifting Height:
65mm
Fork Length:
800mm
Fork Width:
215~650mm
Certification:
CE/ISO9001
After-sales Service Provided:
Overseas third-party support available
Supply Ability
Supply Ability:
200 Piece/Pieces per Month
Packaging & Delivery
Port
Shanghai
Lead Time :
5~15 days

Detailed Product Description of CPD10S Electric Forklift

Main character

  • Compact and flexible structure
  • Convenient driving with comfortable seat
  • Safe braking is reasonable and reliable
  • Suitable for light load
  • No pollution, no noise



Product Model designation



CPD10-SC10

Drive Unit



Electric

Operation type



Seated

Load capacity

kg

1000

Load center

mm

400

Overall length

mm

2390

Overall width

mm

1004

Overall height

mm

1970

2120

Lift height

mm

2500

3000

Max working height

mm

3275

3775

Free lift height

mm

140

Fork dimensions

mm

800×100×32

Maximum fork width

mm

215~650

Minimum ground clearance

mm

80

Min. right angle aisle width

mm

1906

Min. aisle width for stacking

mm

2765 for Pallet 1200×800

Mast obliquity

°

1/7

Wheelbase

mm

1260

Front overhang

mm

165

Turning radius

mm

1440

Travel speed

loaded

Km/h

4.9

unloaded

Km/h

6.0

Lift speed

loaded

mm/s

100

unloaded

mm/s

140

Lowering speed

loaded

mm/s

181

unloaded

mm/s

175

Gradeability

%

8

Brake type



Hydraulic

Drive motor power

KW

2.0

lift motor power

KW

2.0

Battery capacity/voltage

Ah/V

300/24

Weight (without battery)

kg

1465/1490

Battery weight

kg

275















































































-CPD



Packaging & Shipping

  copy





Company Information

       Our factory has been built up for about 40 years. We are a Manufactory which mainly produce Electric forklifts, includes Electric Pallet Truck, Electric Stacker, Electric Reach Truck and so on. We do OEM for many trading companies. Our products mainly exported toEuropean Market. -
