1500kg Side Tiller Goods Lift

FOB Reference Price:Get Latest Price
1 Piece/Pieces (Min. Order)
Supply Ability:
500 Piece/Pieces per Month
Port:
Shanghai
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
MEISHI
Model Number:
CDD15-C15
Type:
Lift Truck
Power Souce:
DC Motor
Rated Loading Capacity:
1200-1500kg
Max. Lifting Height:
3300mm
Min. Lifting Height:
90mm
Fork Length:
1150mm
Fork Width:
540mm
Certification:
CE/ISO9001
After-sales Service Provided:
Overseas third-party support available
Packaging & Delivery
Delivery Time
10~15 days

Product Description



Detailed Product Description of CDDC Side Steer Goods Lift

Main Character



  • Convenient operation with side-installed drive device
  • Steady and safe traveling ,compact reasonable structure and high-quality material
  • Imported control system,pump station and so on,makes good quality
  • Optional imported handle



Product Model designation



CDD12C/CDD15C

Drive Unit



Electric

Operation type



Pedestrian

Load capacity

kg

1200/1500

Load center

mm

600

Overall length

mm

1924

Overall width

mm

840

Overall height

mm

1800

2025

2125

2225

Lift height

mm

2450

2900

3100

3300

Max working height

mm

3094

3544

3744

3944

Lowered fork height

mm

90

Fork dimensions

mm

1150×160×56

Maximum fork width

mm

540

Min. aisle width for stacking

mm

2350

Wheelbase

mm

1279

Turning radius

mm

1510

Travel speed

loaded

Km/h

4.5

unloaded

Km/h

6.0

Lift speed

loaded

mm/s

80

unloaded

mm/s

170

Lowering speed

loaded

mm/s

85

unloaded

mm/s

80

Brake type



Electric-magnetic

Drive motor power

KW

1.2

lift motor power

KW

2.2

Battery capacity/voltage

Ah/V

165/24

Weight without battery

kg

648

670

681

691

Battery weight

kg

160






































































Company Information

   Our factory has been built up for about 40 years. We are a Manufactory which mainly produce Electric forklifts, includes Electric Pallet Truck, Electric Stacker, Electric Reach Truck and so on. We do OEM for many trading companies. Our products mainly exported to European Market.
