Compact structure, solid carriage with strong traction power.
210Ah large capacity battery, keeps long-time working.
Top quality CURTIS controller, makes the truck reacts quickly and operaters easily
Product Model designation
QD20
Drive Unit
Electric
Operation type
Standing
Traction weight
kg
2000
Overall length
mm
1450
Overall width
mm
730
Overall height
mm
1575
Wheelbase
mm
1000
Minimum ground clearance
mm
90
Turning radius
mm
1250
Travel speed
loaded
Km/h
4.3
unloaded
Km/h
7.4
Brake type
Electric-magnetic
Drive motor power
KW
1.2
Battery capacity/voltage
Ah/V
210/24
Weight without battery
kg
425
Battery weight
kg
185
Packaging & Shipping
Company Information
Our factory has been built up for about 40 years. We are a Manufactory which mainly produce Electric forklifts, includes Electric Pallet Truck, Electric Stacker, Electric Reach Truck and so on. We do OEM for many trading companies. Our products mainly exported toEuropean Market.
